Tata Signa 2823.K Base
Variants
Key Specifications of Tata Signa 2823.K Base Truck
-
Engine Type
Water cooled direct injection Turbo charged intercooled Diesel Engine with E viscous fan -
Max Power
227 HP at 2500 rpm -
Max Torque
810 Nm at 1100 to 1800 rpm -
Power Steering
Hyrdaulic Power Steering -
Wheelbase (mm)
3880 mm -
Gross vehicle weight (Kgs)
28000 Kg
Specifications of Tata Signa 2823.K Base
- Engine Cummins ISB5.9 B4S230T1
- Engine Type Water cooled direct injection Turbo charged intercooled Diesel Engine with E viscous fan
- Body Type TATA SIGNA 2823.K CRe HD BSIV
- Engine Capacity 5883
- Engine Power 227 HP at 2500 rpm
- No of Cylinders 6
- Max Speed 89 kmph
- Emission BS IV
- Torque 810 Nm at 1100 to 1800 rpm
- Gradeability 42%
- Gear Box TATA G1150-9 SPEED DD WITH PTO
- Clutch 380 dia
- Steering System Hyrdaulic Power Steering
- Brakes Service Brakes- Dual circuit Full Air S-cam with ABS Auxillary Brake - Engine exhaust brake
- Suspension Semi elliptical spring at Front & Bogie Suspension at rear
- Suspension - Front Semielliptical
- Suspension - Rear Bogie Suspension
- Shock absorber Hydraulic double acting telescopic type at front
- Antiroll Bar At Front & rear
- No of Tyres 10+1
- Tyre Size 10-20 16PR
- Axle - Front Extra Heavy duty forged I beam Reverse Elliot type
- Axle - Rear RA 109 SRT
- Axle Final ratio 6.14
- Wheelbase 3880 mm
- Ground Clearance 238 mm
- Overall Length 7101mm
- Overall Width 2592 mm
- Overall Height (Unladen) 3205 mm
- Turning Circle Radius 8500 mm
- GVW 28000 Kg
- Kerb Weight 11263 Kg
- Max Permissible FAW 7000 Kg
- Max Permissible RAW 21000 Kg
- Fuel Tank Capacity 300L
- Cabin Signa Cab
- Cabin Ventilation AC
