Force Motors Trax Cruiser
Variants
Key Specifications of Force Motors Trax Cruiser Truck
-
Fuel Tank Capacity
60 Litres -
Wheelbase (mm)
3050 -
Max Power
60 HP @ 3200 rpm -
Max Torque
158 Nm @ 2000-2200 rpm -
Seating Capacity
13+D -
Fuel Type
Diesel
Specifications of Force Motors Trax Cruiser
- Model TD2650 F(II EG)
- Emission BS-III
- Engine Type 4 Cylinder, DI
- Displacement 2596 CC
- Max Output 60 HP @ 3200 rpm
- Max Torque 158 Nm @ 2000-2200 rpm
- Transmission Type Synchromesh
- No. of gears 5 Forward & 1 Reverse (5th gear – overdrive)
- Front Axle Independent
- Rear Axle Live Rigid
- Front Suspension Independent With Solid Torsion Bar, Hydraulic Telescopic Shock Absorbers and Anti Roll Bar
- Rear Suspension Semi Elliptical Two Stage Leaf Springs with Hydraulic Telescopic Shock Absorbers
- Steering Type Mechanical (Power Steering-Optional)
- Turning Radius 6.3 Meters
- Service Brakes Hydraulic-Dual Circuit (Vacuum Assisted)
- Front Brakes Disc Brakes
- Rear Brakes Drum Brakes
- Parking Mechanical on Rear Wheels
- Wheels & Tyres Size 7.00 R 15 / 215 / 75 R 15
- Wheel Base (mm) 3050
- Overall length (mm) 4832
- Overall Width (mm) 1660
- Overall height (mm) 2055
- Overhang Front (mm) 707
- Overhang Rear (mm) 1075
- Ground Clearance (mm) 210
- Max. Permissible FAW 1090
- Max. Permissible RAW 1760
- Max. Permissible GVW 2850
- Fuel Tank Capacity 60 Litres
- Seating Capacity 13+D
