Bharat Benz 3123R 7300 (24 ft)

Specifications of Bharat Benz 3123R 7300 (24 ft)

• Wheel Base 5775
• Overall Length 9867
• Overall Width 2490
• Overall Height 2960
• Rear Overhang 1957
• MINIMUM GROUND CLEARANCE 264
• Load Body Length 7300 (24 ft)
• Gross Vehicle Weight (GVW) 31,000 kg
• Model DE170BS3
• Maximum Power 170 kW (231hp) @ 2200 RPM
• Maximum Torque 810 Nm @ 1200 – 1600 rpm
• No. of cylinders, Displacement 6 Nos., 6373 cc
• Gearbox Model & Type G 85 – 6F + 1R, Mechanical, Synchromesh Gears
• Clutch Type, Diameter Single dry plate, Hydraulic actuated, 395 mm
• Chassis Type Channel Section with cross member
• Depth x Flange Width x Thickness 284 mm x 70 mm x 7mm
• Front Suspension Parabolic type leaf spring with 2 hydraulic shock absorbers
• Pusher Axle Suspension Air bellow
• Rear Suspension Balancer type semi elliptic leaf spring
• Anti-roll bar Standard on both axles
• Service brake Pneumatic, Foot Operated, Dual Line
• Parking Brake Hand control valve acting on rear axle
• Wheel Rims & Tyre 7.5″ x 20″ & Radial 10.00 R 20- 16 PR/ (Optional) Crossply 10.00 x 20 – 16PR
• Steering Type Hydraulic Power Assisted
• Cabin Sleeper Cabin with Berth, Tiltable
• F.I.P. Unitized
• Fuel Tank Fuel Tank
• Voltage 24 V Electrical System
• Battery Capacity 2 x 12V, 120 Ah
• 2 x 12V, 120 Ah 18.3%
• Maximum Grade Speed Maximum Grade Speed
• Minimum Turning Circle Diameter 7300-21.6m
• Standard Cabin & Chassis
• Load Body Option Fixed Side Deck & High Side Deck
• Option Packs Comfort Pack (HVAC), Hazardous Goods Pack & High CG Pack
