Ashok Leyland Super Stallion 10x10 7712
Variants
}
Key Specifications of Ashok Leyland Super Stallion 10x10 7712 Truck
-
Engine Type
In-Line 6 Cylinder Diesel -
Max Power
330 kw (450 hp) at 2200 rpm -
Max Torque
1600 Nm at 1300 rpm -
Fuel Tank Capacity
400 L -
Payload Capacity
Upto 29000 -
Wheelbase (mm)
7712
Specifications of Ashok Leyland Super Stallion 10x10 7712
- Engine In-Line 6 Cylinder Diesel
- MAXIMUM POWER 330 kw (450 hp) at 2200 rpm
- MINIMUM TORQUE 1600 Nm at 1300 rpm
- Fuel Tank Capacity 400 L
- Emission norms BS III
- Max. Power Speed 90 kmph
- Max. Gradeability 30 degree
- Min. Turning Circle Diameter 26 m, 34 m
- Side Slope Stability 15 degree
- Step Climbing 500 mm
- Trench Crossing 2000 mm
- Fordability 1000 mm
- Unladen 15000
- Laden Upto 44000
- Payload Upto 29000
- Wheel Base 7712
- Overall Length 13814
- Overall Height 3250
- Overall Width 2550
- Ground Clearance 400
- Loading Span 10764
- Clutch Type Diaphragm pull type or torque converter
- GEAR BOX Type Manual / Automatic
- TRANSFER CASE Type Twin speed
- AXLES Type Hub reduction axles with provision for inter-axle lock and inter wheel differential lock
- Suspension Type Front : Parabolic with shock absorbers Rear I & II : Bogie Rear III : Multi leaf
- Steering Type Integral power Steering
- BRAKES TYPE Dual Line – Full air brakes with ABS
